Stone cutting machine water jet machine

• Place of Origin:

   China

• Type:

  Others

• Genre:

  Machinery & Equipment

• sCode:

  STPR1470824

• Place of Origin:

  China
• 1.1.3Chief technical parameter
  - structure：Bridge
  - size（X×Y）：3600mm?2100mm
  - work area
  - X-axis：3500mm
  - Y-axis：2000mm
  - Z-axis：150mm
  - repeatability：0.025mm
  - X、Y speed：0-15m/min
  - controlling accuracy：±0.01mm
  - cutting accuracy：±0.1mm
  power：380VAC, 50Hz , 3 phase 4 wire system (can be customized)
  1.1.4Transmission system
  - We adopt ABBA (Taiwan) ball screw and HIWIN (Taiwan) lead rail to ensure accuracy
  durable and quality.

  1.1.5Prevention system
  - Over travel auto spacing function and soft spacing function
  - Unique prevention design: new mazy protection and z-axis totally enclosed professional design prevent sand and water from eroding the guide screw and lead rail.

  1.1.6Lubrication system
  - We adopt auto mass lubrication system to make oil reach every oil site on time and also make table steadier and easier.
